TBT-0610
| Availability: | |
|---|---|
The Thin Film Oven is design and made as pe Thin Film Oven Test in the industrial standard and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering.
It is suitable to test the quality loss after heating the road asphalt film. And also test the change of needle penetration, softening point, breaking point and ductility for asphalt residue as need to evaluate the aging resistance property of asphalt.
The Thin Film Oven is design and made as pe Thin Film Oven Test in the industrial standard and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering.
It is suitable to test the quality loss after heating the road asphalt film. And also test the change of needle penetration, softening point, breaking point and ductility for asphalt residue as need to evaluate the aging resistance property of asphalt.
1.This Oven is composed of electric control component, working oven and mechanical drive. An illuminating light is equipped in the oven for convenient observation.
2.There is an air compressor in the oven to supply the air needed for the test. The air can be controlled by a flowmeter on the panel.
3.It adopts high precise temperature controller which can meet test requirements.
1.This Oven is composed of electric control component, working oven and mechanical drive. An illuminating light is equipped in the oven for convenient observation.
2.There is an air compressor in the oven to supply the air needed for the test. The air can be controlled by a flowmeter on the panel.
3.It adopts high precise temperature controller which can meet test requirements.
Power supply | 220VAC 50HZ |
Heating power | 2.4kW |
Working temperature | 163℃ |
Temperature control precision | ±0.5℃ |
Rotating speed of turn plate | (15±0.2) r /min |
Air flow rate | (4000±200) mL /min |
Timing unit | Alert at 85 min |
Ambient temperature | (5~50)℃ |
Relative humidity | ≤85% |
Maximum power consumption | 2.6kW |
Power supply | 220VAC 50HZ |
Heating power | 2.4kW |
Working temperature | 163℃ |
Temperature control precision | ±0.5℃ |
Rotating speed of turn plate | (15±0.2) r /min |
Air flow rate | (4000±200) mL /min |
Timing unit | Alert at 85 min |
Ambient temperature | (5~50)℃ |
Relative humidity | ≤85% |
Maximum power consumption | 2.6kW |
No. | Name | Unit | Qty | Memo |
1 | Asphalt Rolling Thin Film Oven | Set | 1 | |
2 | Sample bottle | Piece | 8 | |
3 | Mercury thermometer (150-170℃, scale division is 0.5℃) | Piece | 1 | |
4 | Fuse 20A（Φ6×30） | Piece | 2 | Reserve |
5 | Socket（250V 16A three-core） | Piece | 1 | |
6 | Illuminating lamp(installed by user) | Piece | 1 | One as reserve |
7 | Operation manual | Piece | 2 | |
8 | Temperature control device usage manual | Piece | 1 | |
9 | Quality certificate | Piece | 1 | |
10 | Repair guarantee | Piece | 1 |
No. | Name | Unit | Qty | Memo |
1 | Asphalt Rolling Thin Film Oven | Set | 1 | |
2 | Sample bottle | Piece | 8 | |
3 | Mercury thermometer (150-170℃, scale division is 0.5℃) | Piece | 1 | |
4 | Fuse 20A（Φ6×30） | Piece | 2 | Reserve |
5 | Socket（250V 16A three-core） | Piece | 1 | |
6 | Illuminating lamp(installed by user) | Piece | 1 | One as reserve |
7 | Operation manual | Piece | 2 | |
8 | Temperature control device usage manual | Piece | 1 | |
9 | Quality certificate | Piece | 1 | |
10 | Repair guarantee | Piece | 1 |
