TBTACX-I & TBTACX-II
TBTSCIETECH
TBTACX-1
| Availability: | |
|---|---|
TBTACX-I & TBTACX-II Asphalt Slab Roller Compactor are designed to molding the bitumious mixture sample slabs of a target density, which to be used in highway construction.
TBTACX-I adopts hydraulic method, TBTACX-II adopts penumatic method.
Compare with the similar products, it has the advantages of small dimension, high automation, strong function and convenient operating.
The mould size can be customized according to customer’s requirement.
Features:
1. Equip with color touch screen, make the operating, data displaying and parameter inputting more convenient.
2. The temperature, compacting times and other parameters will be displayed real time.
3. Real time inspection of compacting pressure ensures test is carried out under the correct compacter pressure.
4. Equip with automatic alarm function when the compacter pressure exceeds 3% of the set pressure to inform the operator to respond accordingly.
5. The height of the test mold can be set and adjusted in the range of (30 ~ 100) mm.
TBTACX-I & TBTACX-II Asphalt Slab Roller Compactor are designed to molding the bitumious mixture sample slabs of a target density, which to be used in highway construction.
TBTACX-I adopts hydraulic method, TBTACX-II adopts penumatic method.
Compare with the similar products, it has the advantages of small dimension, high automation, strong function and convenient operating.
The mould size can be customized according to customer’s requirement.
Features:
1. Equip with color touch screen, make the operating, data displaying and parameter inputting more convenient.
2. The temperature, compacting times and other parameters will be displayed real time.
3. Real time inspection of compacting pressure ensures test is carried out under the correct compacter pressure.
4. Equip with automatic alarm function when the compacter pressure exceeds 3% of the set pressure to inform the operator to respond accordingly.
5. The height of the test mold can be set and adjusted in the range of (30 ~ 100) mm.
Technical Specification
Compacting wheel | radius 500mm width 300mm |
Compacting wheel temperature control range | ambient temperature ~200℃ |
Compacting wheel temperature control accuracy | ±3℃ |
Compacting speed | 6 times / min ± 0.5 times / min |
Compacting time | can be set in the software |
default is P1:4times P2:12times | |
Test mould size | 300mm*300mm*(30~100)mm |
Dimension | Around 1200mm*700mm*2000mm |
Weight | Around 350KG |
Power supply | 380VAC, 50Hz |
Technical Specification
Compacting wheel | radius 500mm width 300mm |
Compacting wheel temperature control range | ambient temperature ~200℃ |
Compacting wheel temperature control accuracy | ±3℃ |
Compacting speed | 6 times / min ± 0.5 times / min |
Compacting time | can be set in the software |
default is P1:4times P2:12times | |
Test mould size | 300mm*300mm*(30~100)mm |
Dimension | Around 1200mm*700mm*2000mm |
Weight | Around 350KG |
Power supply | 380VAC, 50Hz |
