TBT-0722
TBTSCIETECH
| Availability: | |
|---|---|
The instrument is designed and made as per Standard Test Method for Bitumen Content of Bituminous Mixture by the Centrifuge Separation Method in Industrial Standard and ASTM D2172 Specification and Test Methods for Bitumen and Bituminous Mixture for Highway Engineering.
The instrument is designed and made as per Standard Test Method for Bitumen Content of Bituminous Mixture by the Centrifuge Separation Method in Industrial Standard and ASTM D2172 Specification and Test Methods for Bitumen and Bituminous Mixture for Highway Engineering.
1. Thicken aluminum alloy vessel. Stainless steel centrifugal shaft and instrument shell. Never rust .
2. Precise mechanical manufacturing technology. The rotation is stable and speed is fast.
3. Digital display timer.Multilevel start. Stable test operation.
1. Thicken aluminum alloy vessel. Stainless steel centrifugal shaft and instrument shell. Never rust .
2. Precise mechanical manufacturing technology. The rotation is stable and speed is fast.
3. Digital display timer.Multilevel start. Stable test operation.
Rated rotation speed | 3000r/min |
Power supply | AC（220±10%）V，50Hz |
Volume | 3000g |
Timer | 40, 60, 80, 99（s） |
Maximum power consumption | 550W |
Ambient temperature | -10℃～35℃ |
Relative humidity | ≤85% |
Net weight | 45Kg |
Dimension | Main unit：Ф365mm×400mm Control box：200mm×120mm×100mm |
Rated rotation speed | 3000r/min |
Power supply | AC（220±10%）V，50Hz |
Volume | 3000g |
Timer | 40, 60, 80, 99（s） |
Maximum power consumption | 550W |
Ambient temperature | -10℃～35℃ |
Relative humidity | ≤85% |
Net weight | 45Kg |
Dimension | Main unit：Ф365mm×400mm Control box：200mm×120mm×100mm |
No. | Name | Unit | Qty |
1 | Centrifugal Extractor | Set | 1 |
2 | Control box | Set | 1 |
3 | Filter paper | Piece | 30 |
4 | Fasten-on-wall metal parts | Set | 1 |
5 | Silicone oil | Bottle | 1 |
6 | Operation manual | Piece | 1 |
7 | Quality certificate | Piece | 1 |
8 | Repair guarantee | Piece | 1 |
No. | Name | Unit | Qty |
1 | Centrifugal Extractor | Set | 1 |
2 | Control box | Set | 1 |
3 | Filter paper | Piece | 30 |
4 | Fasten-on-wall metal parts | Set | 1 |
5 | Silicone oil | Bottle | 1 |
6 | Operation manual | Piece | 1 |
7 | Quality certificate | Piece | 1 |
8 | Repair guarantee | Piece | 1 |
