TBTVM -1C
TBTSCIETECH
| Availability: | |
|---|---|
TBTVM-1C is designed and made as per T0625 “Asphalt Rotation Viscosity Test (Brookfield Viscometer Methods)” in the Industry Standard JTJ052 Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering.
It is suitable to determine absolute viscosity of Newton liquids and apparent viscosity of non-Newton liquids. It is sensitive, reliable, convenient, beautiful, and it only needs little sample. It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and other liquids.
TBTVM-1C is designed and made as per T0625 “Asphalt Rotation Viscosity Test (Brookfield Viscometer Methods)” in the Industry Standard JTJ052 Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering.
It is suitable to determine absolute viscosity of Newton liquids and apparent viscosity of non-Newton liquids. It is sensitive, reliable, convenient, beautiful, and it only needs little sample. It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and other liquids.
1. Adopts the advanced mechanical design technologies and manufacturing techniques, and uses microcomputer technologies for temperature control, data collection and data process.
2. The display is a background light, ultra-brighten LCD.
3. It is also equipped with a micro-printer for printing.
4. The test data can be shown on the LCD in real time or printed out through the printer.
5. It can also connect to a computer through the RS232 communication port.
6. The instrument has characteristics of high measurement sensitivity, reliable measurement data, convenience, and good looking.
7. It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and various fluids.
1. Adopts the advanced mechanical design technologies and manufacturing techniques, and uses microcomputer technologies for temperature control, data collection and data process.
2. The display is a background light, ultra-brighten LCD.
3. It is also equipped with a micro-printer for printing.
4. The test data can be shown on the LCD in real time or printed out through the printer.
5. It can also connect to a computer through the RS232 communication port.
6. The instrument has characteristics of high measurement sensitivity, reliable measurement data, convenience, and good looking.
7. It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and various fluids.
Measurement range | 100 mPa·s~2×105 mPa·s (If select the No.30 spindle, the measurement range can be extended to 4×105 mPa·s) |
Spindle | No.21, 27, 28 and 29 total 4 pieces of spindles (No.30 spindle is optional) |
Rotation speed | 5RPM, 10 RPM, 20 RPM, and 50 RPM |
Measurement error | ±1% (F·S) |
Temperature control range | 20℃~200℃ |
Temperature control accuracy | ±0.1℃ |
Sample cylinder | 20 ml |
Power supply | 220VAC 50Hz |
Ambient temperature | 5℃~35℃ (when the controlling temperature is close to ambient temperature, please run the air conditioner to let the ambient temperature be 5℃ lower than the controlling temperature) |
Relative humidity | ≤80% |
Measurement range | 100 mPa·s~2×105 mPa·s (If select the No.30 spindle, the measurement range can be extended to 4×105 mPa·s) |
Spindle | No.21, 27, 28 and 29 total 4 pieces of spindles (No.30 spindle is optional) |
Rotation speed | 5RPM, 10 RPM, 20 RPM, and 50 RPM |
Measurement error | ±1% (F·S) |
Temperature control range | 20℃~200℃ |
Temperature control accuracy | ±0.1℃ |
Sample cylinder | 20 ml |
Power supply | 220VAC 50Hz |
Ambient temperature | 5℃~35℃ (when the controlling temperature is close to ambient temperature, please run the air conditioner to let the ambient temperature be 5℃ lower than the controlling temperature) |
Relative humidity | ≤80% |
