TBT-0610W
TBTSCIETECH
| Availability: | |
|---|---|
TBT-0610W is suitable to determine mass loss of highway asphalt rolling thin film after heating, and the change of penetration, viscosity, ductility and breaking point of asphalt residue after the thin film has been heated, so as to assess the aging performance of bitumen after simulated short term aged asphalt binder for physical property testing.
TBT-0610W is suitable to determine mass loss of highway asphalt rolling thin film after heating, and the change of penetration, viscosity, ductility and breaking point of asphalt residue after the thin film has been heated, so as to assess the aging performance of bitumen after simulated short term aged asphalt binder for physical property testing.
1. Inner chamber made of stainless steel;
2. Internal air compressor to supply the air needed for the test which can be controlled by flowmeter;
3. Adopts high precise temperature controller;
4. Temperature will recover to 163℃ within 10 minutes after installing the specimen;
5. Equip with timer, when reaching setting time machine will power off automatically to avoid over-aging;
6. Observe window & lighting lamp for checking the indoor thermometer reading and specimen status.
1. Inner chamber made of stainless steel;
2. Internal air compressor to supply the air needed for the test which can be controlled by flowmeter;
3. Adopts high precise temperature controller;
4. Temperature will recover to 163℃ within 10 minutes after installing the specimen;
5. Equip with timer, when reaching setting time machine will power off automatically to avoid over-aging;
6. Observe window & lighting lamp for checking the indoor thermometer reading and specimen status.
Working temperature | 163℃ |
Temperature control precision | ±0.5℃ |
Speed of rotating disk | 15±0.2 rpm |
Air flow rate | 4000±200 mL /min |
Motor speed | 1725±100 rpm |
Timer | Alert at 85 min |
Ambient temperature | 15~35℃ |
Relative humidity | ≤85% |
Power supply | 220V, 50Hz |
Heating power | 2.2KW |
Working temperature | 163℃ |
Temperature control precision | ±0.5℃ |
Speed of rotating disk | 15±0.2 rpm |
Air flow rate | 4000±200 mL /min |
Motor speed | 1725±100 rpm |
Timer | Alert at 85 min |
Ambient temperature | 15~35℃ |
Relative humidity | ≤85% |
Power supply | 220V, 50Hz |
Heating power | 2.2KW |
